Assistent 128 - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
asst128	pc/asst128.cpp		no	no	no	yes	Assistent 128	198?	Schetmash	ibm5150	ibm5150

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
board0:cga_mc1502:screen	raster	0	640	400	37.973722	16000000	912	0	640	462	0	400	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
extbios.bin	8192	e3bf22de	d4319edc82c0015ca0adc6c8771e887659717e62	bios	4000	good	no
basic.bin	32768	a4ec66f6	80e934986022681ccde180e92aa108e716c4f19b	bios	6000	good	no
mainbios.bin	8192	8426cbf5	41d14137ffa651977041da22aa8071c0f7854158	bios	e000	good	no
asst128cg.bin	8192			gfx1	0	nodump	no

chip

type	tag	name	clock
cpu	maincpu	Intel 8086	4772720
cpu	mb:dma8237	AM9517A	4772727
cpu	kbd:pcxt:i8048	Intel 8048	5102535
audio	mb:mono	Speaker
audio	mb:speaker	Filtered DAC
audio	mb:cassette	Cassette
audio	fdc:0:525ssqd:flopsndout	Speaker
audio	fdc:0:525ssqd:floppysound	Floppy sound	44100
audio	fdc:1:525ssqd:flopsndout	Speaker
audio	fdc:1:525ssqd:floppysound	Floppy sound	44100

device_ref

name
i8086
asst128_mb
pit8253
pit_counter
pit_counter
pit_counter
am9517a
pic8259
i8255
isa8
speaker
speaker_sound_device
cassette_image
isa8_slot
cga_mc1502
screen
palette
mc6845
isa8_slot
isa_lpt
pc_lpt
centronics
centronics_printer
printer_image
input_buffer
input_buffer
input_buffer
output_latch
output_latch
pc_kbdc
kb_pcxt83
i8048
pc_fdc_xt
upd765a
floppy_connector
floppy_525_ssqd
speaker
flopsnd
floppy_connector
floppy_525_ssqd
speaker
flopsnd
pc_joy
pc_basic_joy
ram

sound

channels
3

feature

type	status	overall
graphics		imperfect

ramoption

name	default
64K
128K
256K
512K	yes

device, instance

type	tag	interface	name	briefname
cassette	mb:cassette	ibm5150_cass	cassette	cass
printout	board1:lpt:lpt:centronics:printer:printer		printout	prin
floppydisk	fdc:0:525ssqd	floppy_5_25	floppydisk1	flop1
floppydisk	fdc:1:525ssqd	floppy_5_25	floppydisk2	flop2

device, extension

type	tag	interface	extension_names
cassette	mb:cassette	ibm5150_cass	wav, flac
printout	board1:lpt:lpt:centronics:printer:printer		prn
floppydisk	fdc:0:525ssqd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, img
floppydisk	fdc:1:525ssqd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, img

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	reverse	minimum	maximum	sensitivity	keydelta
stick	1	2	no	1	255	100	1
keyboard	1	83	no
stick	2	2	no	1	255	100	1

port, analog

port_tag	analog_masks
:board0:cga_mc1502:cga_config
:board1:lpt:DSW
:kbd:pcxt:MD00
:kbd:pcxt:MD01
:kbd:pcxt:MD02
:kbd:pcxt:MD03
:kbd:pcxt:MD04
:kbd:pcxt:MD05
:kbd:pcxt:MD06
:kbd:pcxt:MD07
:kbd:pcxt:MD08
:kbd:pcxt:MD09
:kbd:pcxt:MD10
:kbd:pcxt:MD11
:mb:DSW0
:mb:DSW1
:pc_joy:basic_joy:btn
:pc_joy:basic_joy:x1	255
:pc_joy:basic_joy:x2	255
:pc_joy:basic_joy:y1	255
:pc_joy:basic_joy:y2	255

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
board1:lpt:lpt:centronics	nlq401	nlq401	no
board1:lpt:lpt:centronics	smartboard	centronics_smartboard	no
board1:lpt:lpt:centronics	chessmec	centronics_chessmec	no
board1:lpt:lpt:centronics	samdac	centronics_samdac	no
board1:lpt:lpt:centronics	covox_stereo	covox_stereo	no
board1:lpt:lpt:centronics	adaptator	adaptator_multitap	no
board1:lpt:lpt:centronics	digiblst	cpcdigiblst	no
board1:lpt:lpt:centronics	lx800	lx800	no
board1:lpt:lpt:centronics	jx80	epson_jx80	no
board1:lpt:lpt:centronics	ap2000	ap2000	no
board1:lpt:lpt:centronics	ex800	ex800	no
board1:lpt:lpt:centronics	fx80	epson_fx80	no
board1:lpt:lpt:centronics	rx80	epson_rx80	no
board1:lpt:lpt:centronics	covox	covox	no
board1:lpt:lpt:centronics	pl80	comx_pl80	no
board1:lpt:lpt:centronics	lx810l	lx810l	no
board1:lpt:lpt:centronics	p72	p72	no
board1:lpt:lpt:centronics	printer	centronics_printer	yes
kbd	iskr1030	kb_iskr1030	no
kbd	ec1841	kb_ec1841	no
kbd	pcxt	kb_pcxt83	yes
kbd	pc	kb_pc83	no
kbd	keytronc_pc3270	keytronic_pc3270	no
fdc:0	525ssqd	floppy_525_ssqd	yes
fdc:1	525ssqd	floppy_525_ssqd	yes
pc_joy	mssw_pad	mssw_pad	no
pc_joy	magnum6_pad	magnum6_pad	no
pc_joy	basic_joy	pc_basic_joy	yes

configuration

CGA character set

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA character set	board0:cga_mc1502:cga_config	3

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Alternative	1	no

CGA monitor type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA monitor type	board0:cga_mc1502:cga_config	28

setting

name	value	default
Colour RGB	0	yes
Mono RGB	4	no
Colour composite	8	no
Television	12	no
LCD	16	no

CGA chipset

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA chipset	board0:cga_mc1502:cga_config	224

setting

name	value	default
IBM	0	yes
Amstrad PC1512	32	no
Amstrad PPC512	64	no
ATI	96	no
Paradise	128	no

dipswitch

Base address

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Base address	board1:lpt:DSW	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
0x378	0	yes
0x278	1	no

Boot from floppy

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot from floppy	mb:DSW0	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Yes	1	yes
No	0	no

8087 installed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
8087 installed	mb:DSW0	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	2	no

Base RAM size

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Base RAM size	mb:DSW0	12

location

name	number	inverted
SW1	3	no
SW1	4	no

value

name	value	default
16K	0	no
32K	4	no
48K	8	no
64K	12	yes

Graphics adapter

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Graphics adapter	mb:DSW0	48

location

name	number	inverted
SW1	5	no
SW1	6	no

value

name	value	default
EGA/VGA	0	no
Color 40x25	16	no
Color 80x25	32	yes
Monochrome	48	no

Number of floppy drives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Number of floppy drives	mb:DSW0	192

location

name	number	inverted
SW1	7	no
SW1	8	no

value

name	value	default
1	0	no
2	64	yes
3	128	no
4	192	no

Extra RAM size

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Extra RAM size	mb:DSW1	31

location

name	number	inverted
SW2	1	no
SW2	2	no
SW2	3	no
SW2	4	no
SW2	5	no

value

name	value	default
None	0	no
32K	1	no
64K	2	no
96K	3	no
128K	4	no
160K	5	no
192K	6	no
224K	7	no
256K	8	no
288K	9	no
320K	10	no
352K	11	no
384K	12	no
416K	13	no
448K	14	no
480K	15	no
512K	16	no
544K	17	no
576K	18	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	mb:DSW1	224

location

name	number	inverted
SW2	6	no
SW2	7	no
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	224	no
