V630E Baby AT (SiS630 chipset) - mame (0286) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
zidav630e	pc/sis630.cpp		no	no	no	yes	V630E Baby AT (SiS630 chipset)	2001	Zida

snap

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
zidav630e	12779	29/12/2025 11:31:50	720	400	96	96	0	Format24bppRgb	305:MAME 0.256.0 (Jun 28 2023)	21fe25ec2f947f3436f8e2dfc1517e3de1c9e0ee

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
pci:02.0:00.0:screen	raster	0	640	480	53.178707	25174800	900	0	640	526	0	480	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
v630108e.bin	262144	25c91274	95ff37ad0cfb39bb4ceff2db1cd47f13849ea53a	flash	40000	good	no		award_v108

chip

type	tag	name	clock
cpu	maincpu	Intel Pentium III	100000000
cpu	pci:01.0:dmac_master	AM9517A	4772727
cpu	pci:01.0:dmac_slave	AM9517A	4772727
cpu	pci:01.0:keybc:mcu	Intel 8042AH	8250000
cpu	pci:01.0:ps2_con:ms_naturl:ms_natrl_cpu	Intel 8051	6000000
audio	pci:00.1:ide2:0:cdrom:cdda	CD/DA	44100
audio	pci:01.0:mono	Speaker
audio	pci:01.0:speaker	Filtered DAC
audio	superio:it8705f:fdc:0:35hd:flopsndout	Speaker
audio	superio:it8705f:fdc:0:35hd:floppysound	Floppy sound	44100
audio	superio:it8705f:fdc:1:35hd:flopsndout	Speaker
audio	superio:it8705f:fdc:1:35hd:floppysound	Floppy sound	44100

device_ref

tag	name
:maincpu	pentium3
:flash	amd_29f400t
:pci	pci_root
:pci:00.0	sis630_host
:pci:00.1	sis5513_ide
:pci:00.1:ide1	idectrl32bm
:pci:00.1:ide1:0	ata_slot
:pci:00.1:ide1:0:hdd	idehd
:pci:00.1:ide1:0:hdd:image	harddisk_image
:pci:00.1:ide1:1	ata_slot
:pci:00.1:ide2	idectrl32bm
:pci:00.1:ide2:0	ata_slot
:pci:00.1:ide2:0:cdrom	cdrom
:pci:00.1:ide2:0:cdrom:image	cdrom_image
:pci:00.1:ide2:0:cdrom:cdda	cdda
:pci:00.1:ide2:1	ata_slot
:pci:01.0	sis950_lpc
:pci:01.0:pit	pit8254
:pci:01.0:pit:counter0	pit_counter
:pci:01.0:pit:counter1	pit_counter
:pci:01.0:pit:counter2	pit_counter
:pci:01.0:dmac_master	am9517a
:pci:01.0:dmac_slave	am9517a
:pci:01.0:pic_master	pic8259
:pci:01.0:pic_slave	pic8259
:pci:01.0:keybc	ps2_keybc
:pci:01.0:keybc:mcu	i8042ah
:pci:01.0:ps2_con	pc_kbdc
:pci:01.0:ps2_con:ms_naturl	kb_ms_natural
:pci:01.0:ps2_con:ms_naturl:ms_natrl_cpu	i8051
:pci:01.0:aux_con	pc_kbdc
:pci:01.0:rtc	ds12885ext
:pci:01.0:mono	speaker
:pci:01.0:speaker	speaker_sound_device
:pci:01.0:isabus	isa16
:pci:01.0:acpi	lpc_acpi
:pci:01.0:smbus	sis950_smbus
:pci:01.1	sis900_eth
:pci:01.1:eeprom	93c66_16
:pci:01.2	sis7001_usb
:pci:01.3	sis7001_usb
:pci:01.4	sis7018_audio
:pci:01.4:pc_joy	pc_joy
:pci:01.4:pc_joy:basic_joy	pc_basic_joy
:pci:02.0	sis630_bridge
:pci:02.0:00.0	sis630_gui
:pci:02.0:00.0:screen	screen
:pci:02.0:00.0:svga	sis630_vga
:superio	isa16_slot
:superio:it8705f	it8705f
:superio:it8705f:fdc	n82077aa
:superio:it8705f:fdc:0	floppy_connector
:superio:it8705f:fdc:0:35hd	floppy_35_hd
:superio:it8705f:fdc:0:35hd:flopsndout	speaker
:superio:it8705f:fdc:0:35hd:floppysound	flopsnd
:superio:it8705f:fdc:1	floppy_connector
:superio:it8705f:fdc:1:35hd	floppy_35_hd
:superio:it8705f:fdc:1:35hd:flopsndout	speaker
:superio:it8705f:fdc:1:35hd:floppysound	flopsnd
:superio:it8705f:uart0	ns16550
:superio:it8705f:uart1	ns16550
:superio:it8705f:lpta	pc_lpt
:superio:it8705f:lpta:centronics	centronics
:superio:it8705f:lpta:centronics:printer	centronics_printer
:superio:it8705f:lpta:centronics:printer:printer	printer_image
:superio:it8705f:lpta:cent_data_in	input_buffer
:superio:it8705f:lpta:cent_ctrl_in	input_buffer
:superio:it8705f:lpta:cent_status_in	input_buffer
:superio:it8705f:lpta:cent_data_out	output_latch
:superio:it8705f:lpta:cent_ctrl_out	output_latch
:serport0	rs232
:serport0:microsoft_mouse	rs232_mouse_hle_msft
:serport1	rs232

biosset

name	description	default
award_v108	Award BIOS v1.08	no

sound

channels
3

feature

type	status	overall
graphics	imperfect
sound	imperfect	unemulated
mouse		unemulated
media		unemulated
lan		unemulated

device, instance

type	tag	interface	name	briefname
harddisk	pci:00.1:ide1:0:hdd:image	ide_hdd,hdd	harddisk	hard
cdrom	pci:00.1:ide2:0:cdrom:image	cdrom	cdrom	cdrm
floppydisk	superio:it8705f:fdc:0:35hd	floppy_3_5	floppydisk1	flop1
floppydisk	superio:it8705f:fdc:1:35hd	floppy_3_5	floppydisk2	flop2
printout	superio:it8705f:lpta:centronics:printer:printer		printout	prin

device, extension

type	tag	interface	extension_names
harddisk	pci:00.1:ide1:0:hdd:image	ide_hdd,hdd	chd, hd, hdv, 2mg, hdi
cdrom	pci:00.1:ide2:0:cdrom:image	cdrom	chd, cue, toc, nrg, gdi, iso, cdr
floppydisk	superio:it8705f:fdc:0:35hd	floppy_3_5	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf
