King - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
fraking	pc/pc.cpp		no	no	no	yes	King	1989	Frael	ibm5150	ibm5150

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
isa1:cga:screen	raster	0	640	200	59.922748	14318181	912	0	640	262	0	200	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
king3-40.rom	131072	7d64186c	6e3c0d836903bda8c2512fde3bb2ba432705ce27	bios	0	good	no		3.40
king3-42.rom	131072	7c040fda	c5aaa795d773d41c086a80bc43ee7200f53c3a0c	bios	0	good	no		3.42

chip

type	tag	name	clock
cpu	maincpu	NEC V20	8000000
cpu	mb:dma8237	AM9517A	4772727
cpu	kbd:pcxt:i8048	Intel 8048	5102535
audio	mb:mono	Speaker
audio	mb:speaker	Filtered DAC
audio	isa2:fdc_xt:fdc:0:35dd:flopsndout	Speaker
audio	isa2:fdc_xt:fdc:0:35dd:floppysound	Floppy sound	44100

softwarelist

tag	name	status	filter
disk_list	ibm5150	original

device_ref

name
v20
ibm5160_mb
pit8253
pit_counter
pit_counter
pit_counter
am9517a
pic8259
i8255
isa8
speaker
speaker_sound_device
isa8_slot
cga
screen
palette
mc6845
isa8_slot
isa8_fdc_xt
upd765a
floppy_connector
floppy_35_dd
speaker
flopsnd
floppy_connector
isa8_slot
isa8_slot
isa_com
ins8250
ins8250
rs232
rs232_mouse_hle_logitech
rs232
isa8_slot
pc_kbdc
kb_pcxt83
i8048
ram
software_list

biosset

name	description	default
3.40	3.40	no
3.42	3.42	no

sound

channels
2

feature

type	status	overall
graphics		imperfect

ramoption

name	default
64K
128K
256K
512K
768K	yes

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	isa2:fdc_xt:fdc:0:35dd	floppy_3_5			floppydisk	flop

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	isa2:fdc_xt:fdc:0:35dd	floppy_3_5			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, xdf

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
mouse		3		no	0	61440	100
keyboard		83		no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:isa1:cga:cga_config
:isa4:com:serport0:logitech_mouse:BTN
:isa4:com:serport0:logitech_mouse:X	4095
:isa4:com:serport0:logitech_mouse:Y	4095
:kbd:pcxt:MD00
:kbd:pcxt:MD01
:kbd:pcxt:MD02
:kbd:pcxt:MD03
:kbd:pcxt:MD04
:kbd:pcxt:MD05
:kbd:pcxt:MD06
:kbd:pcxt:MD07
:kbd:pcxt:MD08
:kbd:pcxt:MD09
:kbd:pcxt:MD10
:kbd:pcxt:MD11
:mb:DSW0

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
isa1	babyblue2	isa_bblue2	no
isa1	epc_twib	eistwib	no
isa1	finalchs	isa_finalchs	no
isa1	epc_mda	isa_epc_mda	no
isa1	chessmsr	isa_chessmsr	no
isa1	asc88	asc88	no
isa1	pds	isa_pds	no
isa1	prose4k1	isa_prose4001	no
isa1	dectalk	dectalk_isa	no
isa1	lba_enhancer	lba_enhancer	no
isa1	wd1002a_wx1	wd1002a_wx1	no
isa1	lpt	isa_lpt	no
isa1	3c503	el2_3c503	no
isa1	pcmidi	isa_pcmidi	no
isa1	wd90c90_jk	wd90c90_jk	no
isa1	fdc_at	isa8_fdc_at	no
isa1	aga	isa_aga	no
isa1	com	isa_com	no
isa1	chessmdr	isa_chessmdr	no
isa1	ibm_mfc	ibm_mfc	no
isa1	cga_cportiii	cga_cportiii	no
isa1	xtide	xtide	no
isa1	cga_m24	cga_m24	no
isa1	mda	isa_ibm_mda	no
isa1	num9rev	number_9_rev	no
isa1	fdc_ps2	isa8_fdc_ps2	no
isa1	ne1000	ne1000	no
isa1	ega	ega	no
isa1	pgc	isa_ibm_pgc	no
isa1	cga_poisk2	cga_poisk2	no
isa1	stereo_fx	stereo_fx	no
isa1	cga_mc1502	cga_mc1502	no
isa1	cga_ec1841	ec1841_0002	no
isa1	fdc	isa8_fdc_superio	no
isa1	cga	cga	yes
isa1	sblaster1_5	isa_sblaster1_5	no
isa1	wdxt_gen	wdxt_gen	no
isa1	opus108pm	opus108pm	no
isa1	side116	side116	no
isa1	fdc_xt	isa8_fdc_xt	no
isa1	fdc_smc	isa8_fdc_smc	no
isa1	mpu401	isa_mpu401	no
isa1	sblaster1_0	isa_sblaster1_0	no
isa1	aga_pc200	isa_aga_pc200	no
isa1	hdc	isa_hdc	no
isa1	fdc344	fdc344	no
isa1	fdcmag	fdcmag	no
isa1	adlib	isa_adlib	no
isa1	ssi2001	ssi2001	no
isa1	vga	ibm_vga	no
isa1	hercules	isa_hercules	no
isa1	3xtwin	3xtwin	no
isa1	acb2072	acb2072	no
isa1	gblaster	isa_gblaster	no
isa2	babyblue2	isa_bblue2	no
isa2	epc_twib	eistwib	no
isa2	finalchs	isa_finalchs	no
isa2	epc_mda	isa_epc_mda	no
isa2	chessmsr	isa_chessmsr	no
isa2	asc88	asc88	no
isa2	pds	isa_pds	no
isa2	prose4k1	isa_prose4001	no
isa2	dectalk	dectalk_isa	no
isa2	lba_enhancer	lba_enhancer	no
isa2	wd1002a_wx1	wd1002a_wx1	no
isa2	lpt	isa_lpt	no
isa2	3c503	el2_3c503	no
isa2	pcmidi	isa_pcmidi	no
isa2	wd90c90_jk	wd90c90_jk	no
isa2	fdc_at	isa8_fdc_at	no
isa2	aga	isa_aga	no
isa2	com	isa_com	no
isa2	chessmdr	isa_chessmdr	no
isa2	ibm_mfc	ibm_mfc	no
isa2	cga_cportiii	cga_cportiii	no
isa2	xtide	xtide	no
isa2	cga_m24	cga_m24	no
isa2	mda	isa_ibm_mda	no
isa2	num9rev	number_9_rev	no
isa2	fdc_ps2	isa8_fdc_ps2	no
isa2	ne1000	ne1000	no
isa2	ega	ega	no
isa2	pgc	isa_ibm_pgc	no
isa2	cga_poisk2	cga_poisk2	no
isa2	stereo_fx	stereo_fx	no
isa2	cga_mc1502	cga_mc1502	no
isa2	cga_ec1841	ec1841_0002	no
isa2	fdc	isa8_fdc_superio	no
isa2	cga	cga	no
isa2	sblaster1_5	isa_sblaster1_5	no
isa2	wdxt_gen	wdxt_gen	no
isa2	opus108pm	opus108pm	no
isa2	side116	side116	no
isa2	fdc_xt	isa8_fdc_xt	yes
isa2	fdc_smc	isa8_fdc_smc	no
isa2	mpu401	isa_mpu401	no
isa2	sblaster1_0	isa_sblaster1_0	no
isa2	aga_pc200	isa_aga_pc200	no
isa2	hdc	isa_hdc	no
isa2	fdc344	fdc344	no
isa2	fdcmag	fdcmag	no
isa2	adlib	isa_adlib	no
isa2	ssi2001	ssi2001	no
isa2	vga	ibm_vga	no
isa2	hercules	isa_hercules	no
isa2	3xtwin	3xtwin	no
isa2	acb2072	acb2072	no
isa2	gblaster	isa_gblaster	no
isa2:fdc_xt:fdc:1	35dd	floppy_35_dd	no
isa2:fdc_xt:fdc:1	525dd	floppy_525_dd	no
isa3	babyblue2	isa_bblue2	no
isa3	epc_twib	eistwib	no
isa3	finalchs	isa_finalchs	no
isa3	epc_mda	isa_epc_mda	no
isa3	chessmsr	isa_chessmsr	no
isa3	asc88	asc88	no
isa3	pds	isa_pds	no
isa3	prose4k1	isa_prose4001	no
isa3	dectalk	dectalk_isa	no
isa3	lba_enhancer	lba_enhancer	no
isa3	wd1002a_wx1	wd1002a_wx1	no
isa3	lpt	isa_lpt	no
isa3	3c503	el2_3c503	no
isa3	pcmidi	isa_pcmidi	no
isa3	wd90c90_jk	wd90c90_jk	no
isa3	fdc_at	isa8_fdc_at	no
isa3	aga	isa_aga	no
isa3	com	isa_com	no
isa3	chessmdr	isa_chessmdr	no
isa3	ibm_mfc	ibm_mfc	no
isa3	cga_cportiii	cga_cportiii	no
isa3	xtide	xtide	no
isa3	cga_m24	cga_m24	no
isa3	mda	isa_ibm_mda	no
isa3	num9rev	number_9_rev	no
isa3	fdc_ps2	isa8_fdc_ps2	no
isa3	ne1000	ne1000	no
isa3	ega	ega	no
isa3	pgc	isa_ibm_pgc	no
isa3	cga_poisk2	cga_poisk2	no
isa3	stereo_fx	stereo_fx	no
isa3	cga_mc1502	cga_mc1502	no
isa3	cga_ec1841	ec1841_0002	no
isa3	fdc	isa8_fdc_superio	no
isa3	cga	cga	no
isa3	sblaster1_5	isa_sblaster1_5	no
isa3	wdxt_gen	wdxt_gen	no
isa3	opus108pm	opus108pm	no
isa3	side116	side116	no
isa3	fdc_xt	isa8_fdc_xt	no
isa3	fdc_smc	isa8_fdc_smc	no
isa3	mpu401	isa_mpu401	no
isa3	sblaster1_0	isa_sblaster1_0	no
isa3	aga_pc200	isa_aga_pc200	no
isa3	hdc	isa_hdc	no
isa3	fdc344	fdc344	no
isa3	fdcmag	fdcmag	no
isa3	adlib	isa_adlib	no
isa3	ssi2001	ssi2001	no
isa3	vga	ibm_vga	no
isa3	hercules	isa_hercules	no
isa3	3xtwin	3xtwin	no
isa3	acb2072	acb2072	no
isa3	gblaster	isa_gblaster	no
isa4	babyblue2	isa_bblue2	no
isa4	epc_twib	eistwib	no
isa4	finalchs	isa_finalchs	no
isa4	epc_mda	isa_epc_mda	no
isa4	chessmsr	isa_chessmsr	no
isa4	asc88	asc88	no
isa4	pds	isa_pds	no
isa4	prose4k1	isa_prose4001	no
isa4	dectalk	dectalk_isa	no
isa4	lba_enhancer	lba_enhancer	no
isa4	wd1002a_wx1	wd1002a_wx1	no
isa4	lpt	isa_lpt	no
isa4	3c503	el2_3c503	no
isa4	pcmidi	isa_pcmidi	no
isa4	wd90c90_jk	wd90c90_jk	no
isa4	fdc_at	isa8_fdc_at	no
isa4	aga	isa_aga	no
isa4	com	isa_com	yes
isa4	chessmdr	isa_chessmdr	no
isa4	ibm_mfc	ibm_mfc	no
isa4	cga_cportiii	cga_cportiii	no
isa4	xtide	xtide	no
isa4	cga_m24	cga_m24	no
isa4	mda	isa_ibm_mda	no
isa4	num9rev	number_9_rev	no
isa4	fdc_ps2	isa8_fdc_ps2	no
isa4	ne1000	ne1000	no
isa4	ega	ega	no
isa4	pgc	isa_ibm_pgc	no
isa4	cga_poisk2	cga_poisk2	no
isa4	stereo_fx	stereo_fx	no
isa4	cga_mc1502	cga_mc1502	no
isa4	cga_ec1841	ec1841_0002	no
isa4	fdc	isa8_fdc_superio	no
isa4	cga	cga	no
isa4	sblaster1_5	isa_sblaster1_5	no
isa4	wdxt_gen	wdxt_gen	no
isa4	opus108pm	opus108pm	no
isa4	side116	side116	no
isa4	fdc_xt	isa8_fdc_xt	no
isa4	fdc_smc	isa8_fdc_smc	no
isa4	mpu401	isa_mpu401	no
isa4	sblaster1_0	isa_sblaster1_0	no
isa4	aga_pc200	isa_aga_pc200	no
isa4	hdc	isa_hdc	no
isa4	fdc344	fdc344	no
isa4	fdcmag	fdcmag	no
isa4	adlib	isa_adlib	no
isa4	ssi2001	ssi2001	no
isa4	vga	ibm_vga	no
isa4	hercules	isa_hercules	no
isa4	3xtwin	3xtwin	no
isa4	acb2072	acb2072	no
isa4	gblaster	isa_gblaster	no
isa4:com:serport0	null_modem	null_modem	no
isa4:com:serport0	terminal	serial_terminal	no
isa4:com:serport0	msystems_mouse	rs232_mouse_hle_msystems	no
isa4:com:serport0	sun_kbd	sunkbd_adaptor	no
isa4:com:serport0	wheel_mouse	rs232_mouse_hle_wheel	no
isa4:com:serport0	rotatable_mouse	rs232_mouse_hle_rotatable	no
isa4:com:serport0	logitech_mouse	rs232_mouse_hle_logitech	yes
isa4:com:serport0	microsoft_mouse	rs232_mouse_hle_msft	no
isa4:com:serport1	null_modem	null_modem	no
isa4:com:serport1	terminal	serial_terminal	no
isa4:com:serport1	msystems_mouse	rs232_mouse_hle_msystems	no
isa4:com:serport1	sun_kbd	sunkbd_adaptor	no
isa4:com:serport1	wheel_mouse	rs232_mouse_hle_wheel	no
isa4:com:serport1	rotatable_mouse	rs232_mouse_hle_rotatable	no
isa4:com:serport1	logitech_mouse	rs232_mouse_hle_logitech	no
isa4:com:serport1	microsoft_mouse	rs232_mouse_hle_msft	no
isa5	babyblue2	isa_bblue2	no
isa5	epc_twib	eistwib	no
isa5	finalchs	isa_finalchs	no
isa5	epc_mda	isa_epc_mda	no
isa5	chessmsr	isa_chessmsr	no
isa5	asc88	asc88	no
isa5	pds	isa_pds	no
isa5	prose4k1	isa_prose4001	no
isa5	dectalk	dectalk_isa	no
isa5	lba_enhancer	lba_enhancer	no
isa5	wd1002a_wx1	wd1002a_wx1	no
isa5	lpt	isa_lpt	no
isa5	3c503	el2_3c503	no
isa5	pcmidi	isa_pcmidi	no
isa5	wd90c90_jk	wd90c90_jk	no
isa5	fdc_at	isa8_fdc_at	no
isa5	aga	isa_aga	no
isa5	com	isa_com	no
isa5	chessmdr	isa_chessmdr	no
isa5	ibm_mfc	ibm_mfc	no
isa5	cga_cportiii	cga_cportiii	no
isa5	xtide	xtide	no
isa5	cga_m24	cga_m24	no
isa5	mda	isa_ibm_mda	no
isa5	num9rev	number_9_rev	no
isa5	fdc_ps2	isa8_fdc_ps2	no
isa5	ne1000	ne1000	no
isa5	ega	ega	no
isa5	pgc	isa_ibm_pgc	no
isa5	cga_poisk2	cga_poisk2	no
isa5	stereo_fx	stereo_fx	no
isa5	cga_mc1502	cga_mc1502	no
isa5	cga_ec1841	ec1841_0002	no
isa5	fdc	isa8_fdc_superio	no
isa5	cga	cga	no
isa5	sblaster1_5	isa_sblaster1_5	no
isa5	wdxt_gen	wdxt_gen	no
isa5	opus108pm	opus108pm	no
isa5	side116	side116	no
isa5	fdc_xt	isa8_fdc_xt	no
isa5	fdc_smc	isa8_fdc_smc	no
isa5	mpu401	isa_mpu401	no
isa5	sblaster1_0	isa_sblaster1_0	no
isa5	aga_pc200	isa_aga_pc200	no
isa5	hdc	isa_hdc	no
isa5	fdc344	fdc344	no
isa5	fdcmag	fdcmag	no
isa5	adlib	isa_adlib	no
isa5	ssi2001	ssi2001	no
isa5	vga	ibm_vga	no
isa5	hercules	isa_hercules	no
isa5	3xtwin	3xtwin	no
isa5	acb2072	acb2072	no
isa5	gblaster	isa_gblaster	no
kbd	iskr1030	kb_iskr1030	no
kbd	ec1841	kb_ec1841	no
kbd	pcxt	kb_pcxt83	yes
kbd	pc	kb_pc83	no
kbd	keytronc_pc3270	keytronic_pc3270	no

configuration

CGA character set

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA character set	isa1:cga:cga_config	3

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Alternative	1	no

CGA monitor type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA monitor type	isa1:cga:cga_config	28

setting

name	value	default
Colour RGB	0	yes
Mono RGB	4	no
Colour composite	8	no
Television	12	no
LCD	16	no

CGA chipset

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA chipset	isa1:cga:cga_config	224

setting

name	value	default
IBM	0	yes
Amstrad PC1512	32	no
Amstrad PPC512	64	no
ATI	96	no
Paradise	128	no

dipswitch

Game port enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game port enable	DSW1	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	1	no

LPT3: enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
LPT3: enable	DSW1	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	2	no

LPT2: enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
LPT2: enable	DSW1	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	4	no

LPT1: enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
LPT1: enable	DSW1	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

COM4: enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
COM4: enable	DSW1	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	16	no

COM3: enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
COM3: enable	DSW1	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	32	no

COM2: enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
COM2: enable	DSW1	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	64	yes

COM1: enable

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
COM1: enable	DSW1	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	128	yes

HDC2 (CA00:0 port 324-327)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
HDC2 (CA00:0 port 324-327)	DSW2	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	4	yes

HDC1 (C800:0 port 320-323)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
HDC1 (C800:0 port 320-323)	DSW2	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

Boot from floppy

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot from floppy	mb:DSW0	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Yes	1	yes
No	0	no

8087 installed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
8087 installed	mb:DSW0	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	2	no

RAM banks

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RAM banks	mb:DSW0	12

location

name	number	inverted
SW1	3	no
SW1	4	no

value

name	value	default
1 - 16/ 64/256K	0	no
2 - 32/128/512K	4	no
3 - 48/192/576K	8	no
4 - 64/256/640K	12	yes

Graphics adapter

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Graphics adapter	mb:DSW0	48

location

name	number	inverted
SW1	5	no
SW1	6	no

value

name	value	default
EGA/VGA	0	no
Color 40x25	16	no
Color 80x25	32	yes
Monochrome	48	no

Number of floppy drives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Number of floppy drives	mb:DSW0	192

location

name	number	inverted
SW1	7	no
SW1	8	no

value

name	value	default
1	0	no
2	64	yes
3	128	no
4	192	no
