IBM XT 5160 - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
ibm5160	pc/ibmpc.cpp		no	no	no	yes	IBM XT 5160	1982	International Business Machines	ibm5150	ibm5150

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
isa1:cga:screen	raster	0	640	200	59.922748	14318181	912	0	640	262	0	200	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
5000027.u19	32768	fc982309	2aa781a698a21c332398d9bc8503d4f580df0a05	bios	0	good	no		rev1
5000026.u18	32768	3c9b0ac3	271c9f4cef5029a1560075550b67c3395db09fef	bios	8000	good	no		rev1
5000027.u19	32768	fc982309	2aa781a698a21c332398d9bc8503d4f580df0a05	bios	0	good	no		rev2
1501512.u18	32768	79522c3d	6bac726d8d033491d52507278aa388ec04cf8b7e	bios	8000	good	no		rev2
62x0854.u19	32768	b5fb0e83	937b43759ffd472da4fb0fe775b3842f5fb4c3b3	bios	0	good	no		rev3
62x0851.u18	32768	1054f7bd	e7d0155813e4c650085144327581f05486ed1484	bios	8000	good	no		rev3
68x4370.u19	32768	758ff036	045e27a70407d89b7956ecae4d275bd2f6b0f8e2	bios	0	good	no		rev4
62x0890.u18	32768	4f417635	daa61762d3afdd7262e34edf1a3d2df9a05bcebb	bios	8000	good	no		rev4
62x0854.u19	32768	b5fb0e83	937b43759ffd472da4fb0fe775b3842f5fb4c3b3	bios	0	good	no		xtlandmark
5150_or_5160_27256_32kb.bin	32768	d3603216	6691d33f43eddd3b0a6269ef985f5be8705ba55f	bios	8000	good	no		xtlandmark
5788005.u33	8192	0bf56d70	c2a8b10808bf51a3c123ba3eb1e9dd608231916f	gfx1	0	good	no	5788005.u33

chip

type	tag	name	clock
cpu	maincpu	Intel 8088	4772727
cpu	mb:dma8237	AM9517A	4772727
cpu	kbd:pcxt:i8048	Intel 8048	5102535
audio	mb:mono	Speaker
audio	mb:speaker	Filtered DAC
audio	isa3:fdc_xt:fdc:0:525dd:flopsndout	Speaker
audio	isa3:fdc_xt:fdc:0:525dd:floppysound	Floppy sound	44100
audio	isa3:fdc_xt:fdc:1:525dd:flopsndout	Speaker
audio	isa3:fdc_xt:fdc:1:525dd:floppysound	Floppy sound	44100

softwarelist

tag	name	status	filter
pc_disk_list	ibm5150	original
pc_hdd_list	ibm5150_hdd	original

device_ref

name
i8088
ibm5160_mb
pit8253
pit_counter
pit_counter
pit_counter
am9517a
pic8259
i8255
isa8
speaker
speaker_sound_device
isa8_slot
cga
screen
palette
mc6845
isa8_slot
isa_com
ins8250
ins8250
rs232
rs232_mouse_hle_logitech
rs232
isa8_slot
isa8_fdc_xt
upd765a
floppy_connector
floppy_525_dd
speaker
flopsnd
floppy_connector
floppy_525_dd
speaker
flopsnd
isa8_slot
isa_hdc
xt_hdc
harddisk_image
harddisk_image
isa8_slot
isa8_slot
isa8_slot
isa8_slot
pc_kbdc
kb_pcxt83
i8048
ram
software_list
software_list

biosset

name	description	default
rev1	IBM XT 5160 08/16/82	no
rev2	IBM XT 5160 11/08/82	no
rev3	IBM XT 5160 01/10/86	no
rev4	IBM XT 5160 05/09/86	yes
xtlandmark	Landmark/Supersoft Diagnostics	no

sound

channels
3

feature

type	status	overall
graphics		imperfect

ramoption

name	default
64K
128K
256K
512K
640K	yes

device, instance

type	tag	interface	name	briefname
floppydisk	isa3:fdc_xt:fdc:0:525dd	floppy_5_25	floppydisk1	flop1
floppydisk	isa3:fdc_xt:fdc:1:525dd	floppy_5_25	floppydisk2	flop2
harddisk	isa4:hdc:hdc:primary	st_hdd	harddisk1	hard1
harddisk	isa4:hdc:hdc:slave	st_hdd	harddisk2	hard2

device, extension

type	tag	interface	extension_names
floppydisk	isa3:fdc_xt:fdc:0:525dd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, xdf
floppydisk	isa3:fdc_xt:fdc:1:525dd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, xdf
harddisk	isa4:hdc:hdc:primary	st_hdd	chd, hd, hdv, 2mg, hdi
harddisk	isa4:hdc:hdc:slave	st_hdd	chd, hd, hdv, 2mg, hdi

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
mouse		3		no	0	61440	100
keyboard		83		no

port, analog

port_tag	analog_masks
:isa1:cga:cga_config
:isa2:com:serport0:logitech_mouse:BTN
:isa2:com:serport0:logitech_mouse:X	4095
:isa2:com:serport0:logitech_mouse:Y	4095
:isa4:hdc:HDD
:isa4:hdc:ROM
:kbd:pcxt:MD00
:kbd:pcxt:MD01
:kbd:pcxt:MD02
:kbd:pcxt:MD03
:kbd:pcxt:MD04
:kbd:pcxt:MD05
:kbd:pcxt:MD06
:kbd:pcxt:MD07
:kbd:pcxt:MD08
:kbd:pcxt:MD09
:kbd:pcxt:MD10
:kbd:pcxt:MD11
:mb:DSW0

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
isa1	babyblue2	isa_bblue2	no
isa1	epc_twib	eistwib	no
isa1	finalchs	isa_finalchs	no
isa1	epc_mda	isa_epc_mda	no
isa1	chessmsr	isa_chessmsr	no
isa1	asc88	asc88	no
isa1	pds	isa_pds	no
isa1	prose4k1	isa_prose4001	no
isa1	dectalk	dectalk_isa	no
isa1	lba_enhancer	lba_enhancer	no
isa1	wd1002a_wx1	wd1002a_wx1	no
isa1	lpt	isa_lpt	no
isa1	3c503	el2_3c503	no
isa1	pcmidi	isa_pcmidi	no
isa1	wd90c90_jk	wd90c90_jk	no
isa1	fdc_at	isa8_fdc_at	no
isa1	aga	isa_aga	no
isa1	com	isa_com	no
isa1	chessmdr	isa_chessmdr	no
isa1	ibm_mfc	ibm_mfc	no
isa1	cga_cportiii	cga_cportiii	no
isa1	xtide	xtide	no
isa1	cga_m24	cga_m24	no
isa1	mda	isa_ibm_mda	no
isa1	num9rev	number_9_rev	no
isa1	fdc_ps2	isa8_fdc_ps2	no
isa1	ne1000	ne1000	no
isa1	ega	ega	no
isa1	pgc	isa_ibm_pgc	no
isa1	cga_poisk2	cga_poisk2	no
isa1	stereo_fx	stereo_fx	no
isa1	cga_mc1502	cga_mc1502	no
isa1	cga_ec1841	ec1841_0002	no
isa1	fdc	isa8_fdc_superio	no
isa1	cga	cga	yes
isa1	sblaster1_5	isa_sblaster1_5	no
isa1	wdxt_gen	wdxt_gen	no
isa1	opus108pm	opus108pm	no
isa1	side116	side116	no
isa1	fdc_xt	isa8_fdc_xt	no
isa1	fdc_smc	isa8_fdc_smc	no
isa1	mpu401	isa_mpu401	no
isa1	sblaster1_0	isa_sblaster1_0	no
isa1	aga_pc200	isa_aga_pc200	no
isa1	hdc	isa_hdc	no
isa1	fdc344	fdc344	no
isa1	fdcmag	fdcmag	no
isa1	adlib	isa_adlib	no
isa1	ssi2001	ssi2001	no
isa1	vga	ibm_vga	no
isa1	hercules	isa_hercules	no
isa1	3xtwin	3xtwin	no
isa1	acb2072	acb2072	no
isa1	gblaster	isa_gblaster	no
isa2	babyblue2	isa_bblue2	no
isa2	epc_twib	eistwib	no
isa2	finalchs	isa_finalchs	no
isa2	epc_mda	isa_epc_mda	no
isa2	chessmsr	isa_chessmsr	no
isa2	asc88	asc88	no
isa2	pds	isa_pds	no
isa2	prose4k1	isa_prose4001	no
isa2	dectalk	dectalk_isa	no
isa2	lba_enhancer	lba_enhancer	no
isa2	wd1002a_wx1	wd1002a_wx1	no
isa2	lpt	isa_lpt	no
isa2	3c503	el2_3c503	no
isa2	pcmidi	isa_pcmidi	no
isa2	wd90c90_jk	wd90c90_jk	no
isa2	fdc_at	isa8_fdc_at	no
isa2	aga	isa_aga	no
isa2	com	isa_com	yes
isa2	chessmdr	isa_chessmdr	no
isa2	ibm_mfc	ibm_mfc	no
isa2	cga_cportiii	cga_cportiii	no
isa2	xtide	xtide	no
isa2	cga_m24	cga_m24	no
isa2	mda	isa_ibm_mda	no
isa2	num9rev	number_9_rev	no
isa2	fdc_ps2	isa8_fdc_ps2	no
isa2	ne1000	ne1000	no
isa2	ega	ega	no
isa2	pgc	isa_ibm_pgc	no
isa2	cga_poisk2	cga_poisk2	no
isa2	stereo_fx	stereo_fx	no
isa2	cga_mc1502	cga_mc1502	no
isa2	cga_ec1841	ec1841_0002	no
isa2	fdc	isa8_fdc_superio	no
isa2	cga	cga	no
isa2	sblaster1_5	isa_sblaster1_5	no
isa2	wdxt_gen	wdxt_gen	no
isa2	opus108pm	opus108pm	no
isa2	side116	side116	no
isa2	fdc_xt	isa8_fdc_xt	no
isa2	fdc_smc	isa8_fdc_smc	no
isa2	mpu401	isa_mpu401	no
isa2	sblaster1_0	isa_sblaster1_0	no
isa2	aga_pc200	isa_aga_pc200	no
isa2	hdc	isa_hdc	no
isa2	fdc344	fdc344	no
isa2	fdcmag	fdcmag	no
isa2	adlib	isa_adlib	no
isa2	ssi2001	ssi2001	no
isa2	vga	ibm_vga	no
isa2	hercules	isa_hercules	no
isa2	3xtwin	3xtwin	no
isa2	acb2072	acb2072	no
isa2	gblaster	isa_gblaster	no
isa2:com:serport0	null_modem	null_modem	no
isa2:com:serport0	terminal	serial_terminal	no
isa2:com:serport0	msystems_mouse	rs232_mouse_hle_msystems	no
isa2:com:serport0	sun_kbd	sunkbd_adaptor	no
isa2:com:serport0	wheel_mouse	rs232_mouse_hle_wheel	no
isa2:com:serport0	rotatable_mouse	rs232_mouse_hle_rotatable	no
isa2:com:serport0	logitech_mouse	rs232_mouse_hle_logitech	yes
isa2:com:serport0	microsoft_mouse	rs232_mouse_hle_msft	no
isa2:com:serport1	null_modem	null_modem	no
isa2:com:serport1	terminal	serial_terminal	no
isa2:com:serport1	msystems_mouse	rs232_mouse_hle_msystems	no
isa2:com:serport1	sun_kbd	sunkbd_adaptor	no
isa2:com:serport1	wheel_mouse	rs232_mouse_hle_wheel	no
isa2:com:serport1	rotatable_mouse	rs232_mouse_hle_rotatable	no
isa2:com:serport1	logitech_mouse	rs232_mouse_hle_logitech	no
isa2:com:serport1	microsoft_mouse	rs232_mouse_hle_msft	no
isa3	babyblue2	isa_bblue2	no
isa3	epc_twib	eistwib	no
isa3	finalchs	isa_finalchs	no
isa3	epc_mda	isa_epc_mda	no
isa3	chessmsr	isa_chessmsr	no
isa3	asc88	asc88	no
isa3	pds	isa_pds	no
isa3	prose4k1	isa_prose4001	no
isa3	dectalk	dectalk_isa	no
isa3	lba_enhancer	lba_enhancer	no
isa3	wd1002a_wx1	wd1002a_wx1	no
isa3	lpt	isa_lpt	no
isa3	3c503	el2_3c503	no
isa3	pcmidi	isa_pcmidi	no
isa3	wd90c90_jk	wd90c90_jk	no
isa3	fdc_at	isa8_fdc_at	no
isa3	aga	isa_aga	no
isa3	com	isa_com	no
isa3	chessmdr	isa_chessmdr	no
isa3	ibm_mfc	ibm_mfc	no
isa3	cga_cportiii	cga_cportiii	no
isa3	xtide	xtide	no
isa3	cga_m24	cga_m24	no
isa3	mda	isa_ibm_mda	no
isa3	num9rev	number_9_rev	no
isa3	fdc_ps2	isa8_fdc_ps2	no
isa3	ne1000	ne1000	no
isa3	ega	ega	no
isa3	pgc	isa_ibm_pgc	no
isa3	cga_poisk2	cga_poisk2	no
isa3	stereo_fx	stereo_fx	no
isa3	cga_mc1502	cga_mc1502	no
isa3	cga_ec1841	ec1841_0002	no
isa3	fdc	isa8_fdc_superio	no
isa3	cga	cga	no
isa3	sblaster1_5	isa_sblaster1_5	no
isa3	wdxt_gen	wdxt_gen	no
isa3	opus108pm	opus108pm	no
isa3	side116	side116	no
isa3	fdc_xt	isa8_fdc_xt	yes
isa3	fdc_smc	isa8_fdc_smc	no
isa3	mpu401	isa_mpu401	no
isa3	sblaster1_0	isa_sblaster1_0	no
isa3	aga_pc200	isa_aga_pc200	no
isa3	hdc	isa_hdc	no
isa3	fdc344	fdc344	no
isa3	fdcmag	fdcmag	no
isa3	adlib	isa_adlib	no
isa3	ssi2001	ssi2001	no
isa3	vga	ibm_vga	no
isa3	hercules	isa_hercules	no
isa3	3xtwin	3xtwin	no
isa3	acb2072	acb2072	no
isa3	gblaster	isa_gblaster	no
isa3:fdc_xt:fdc:0	35dd	floppy_35_dd	no
isa3:fdc_xt:fdc:0	525dd	floppy_525_dd	yes
isa3:fdc_xt:fdc:1	35dd	floppy_35_dd	no
isa3:fdc_xt:fdc:1	525dd	floppy_525_dd	yes
isa4	babyblue2	isa_bblue2	no
isa4	epc_twib	eistwib	no
isa4	finalchs	isa_finalchs	no
isa4	epc_mda	isa_epc_mda	no
isa4	chessmsr	isa_chessmsr	no
isa4	asc88	asc88	no
isa4	pds	isa_pds	no
isa4	prose4k1	isa_prose4001	no
isa4	dectalk	dectalk_isa	no
isa4	lba_enhancer	lba_enhancer	no
isa4	wd1002a_wx1	wd1002a_wx1	no
isa4	lpt	isa_lpt	no
isa4	3c503	el2_3c503	no
isa4	pcmidi	isa_pcmidi	no
isa4	wd90c90_jk	wd90c90_jk	no
isa4	fdc_at	isa8_fdc_at	no
isa4	aga	isa_aga	no
isa4	com	isa_com	no
isa4	chessmdr	isa_chessmdr	no
isa4	ibm_mfc	ibm_mfc	no
isa4	cga_cportiii	cga_cportiii	no
isa4	xtide	xtide	no
isa4	cga_m24	cga_m24	no
isa4	mda	isa_ibm_mda	no
isa4	num9rev	number_9_rev	no
isa4	fdc_ps2	isa8_fdc_ps2	no
isa4	ne1000	ne1000	no
isa4	ega	ega	no
isa4	pgc	isa_ibm_pgc	no
isa4	cga_poisk2	cga_poisk2	no
isa4	stereo_fx	stereo_fx	no
isa4	cga_mc1502	cga_mc1502	no
isa4	cga_ec1841	ec1841_0002	no
isa4	fdc	isa8_fdc_superio	no
isa4	cga	cga	no
isa4	sblaster1_5	isa_sblaster1_5	no
isa4	wdxt_gen	wdxt_gen	no
isa4	opus108pm	opus108pm	no
isa4	side116	side116	no
isa4	fdc_xt	isa8_fdc_xt	no
isa4	fdc_smc	isa8_fdc_smc	no
isa4	mpu401	isa_mpu401	no
isa4	sblaster1_0	isa_sblaster1_0	no
isa4	aga_pc200	isa_aga_pc200	no
isa4	hdc	isa_hdc	yes
isa4	fdc344	fdc344	no
isa4	fdcmag	fdcmag	no
isa4	adlib	isa_adlib	no
isa4	ssi2001	ssi2001	no
isa4	vga	ibm_vga	no
isa4	hercules	isa_hercules	no
isa4	3xtwin	3xtwin	no
isa4	acb2072	acb2072	no
isa4	gblaster	isa_gblaster	no
isa5	babyblue2	isa_bblue2	no
isa5	epc_twib	eistwib	no
isa5	finalchs	isa_finalchs	no
isa5	epc_mda	isa_epc_mda	no
isa5	chessmsr	isa_chessmsr	no
isa5	asc88	asc88	no
isa5	pds	isa_pds	no
isa5	prose4k1	isa_prose4001	no
isa5	dectalk	dectalk_isa	no
isa5	lba_enhancer	lba_enhancer	no
isa5	wd1002a_wx1	wd1002a_wx1	no
isa5	lpt	isa_lpt	no
isa5	3c503	el2_3c503	no
isa5	pcmidi	isa_pcmidi	no
isa5	wd90c90_jk	wd90c90_jk	no
isa5	fdc_at	isa8_fdc_at	no
isa5	aga	isa_aga	no
isa5	com	isa_com	no
isa5	chessmdr	isa_chessmdr	no
isa5	ibm_mfc	ibm_mfc	no
isa5	cga_cportiii	cga_cportiii	no
isa5	xtide	xtide	no
isa5	cga_m24	cga_m24	no
isa5	mda	isa_ibm_mda	no
isa5	num9rev	number_9_rev	no
isa5	fdc_ps2	isa8_fdc_ps2	no
isa5	ne1000	ne1000	no
isa5	ega	ega	no
isa5	pgc	isa_ibm_pgc	no
isa5	cga_poisk2	cga_poisk2	no
isa5	stereo_fx	stereo_fx	no
isa5	cga_mc1502	cga_mc1502	no
isa5	cga_ec1841	ec1841_0002	no
isa5	fdc	isa8_fdc_superio	no
isa5	cga	cga	no
isa5	sblaster1_5	isa_sblaster1_5	no
isa5	wdxt_gen	wdxt_gen	no
isa5	opus108pm	opus108pm	no
isa5	side116	side116	no
isa5	fdc_xt	isa8_fdc_xt	no
isa5	fdc_smc	isa8_fdc_smc	no
isa5	mpu401	isa_mpu401	no
isa5	sblaster1_0	isa_sblaster1_0	no
isa5	aga_pc200	isa_aga_pc200	no
isa5	hdc	isa_hdc	no
isa5	fdc344	fdc344	no
isa5	fdcmag	fdcmag	no
isa5	adlib	isa_adlib	no
isa5	ssi2001	ssi2001	no
isa5	vga	ibm_vga	no
isa5	hercules	isa_hercules	no
isa5	3xtwin	3xtwin	no
isa5	acb2072	acb2072	no
isa5	gblaster	isa_gblaster	no
isa6	babyblue2	isa_bblue2	no
isa6	epc_twib	eistwib	no
isa6	finalchs	isa_finalchs	no
isa6	epc_mda	isa_epc_mda	no
isa6	chessmsr	isa_chessmsr	no
isa6	asc88	asc88	no
isa6	pds	isa_pds	no
isa6	prose4k1	isa_prose4001	no
isa6	dectalk	dectalk_isa	no
isa6	lba_enhancer	lba_enhancer	no
isa6	wd1002a_wx1	wd1002a_wx1	no
isa6	lpt	isa_lpt	no
isa6	3c503	el2_3c503	no
isa6	pcmidi	isa_pcmidi	no
isa6	wd90c90_jk	wd90c90_jk	no
isa6	fdc_at	isa8_fdc_at	no
isa6	aga	isa_aga	no
isa6	com	isa_com	no
isa6	chessmdr	isa_chessmdr	no
isa6	ibm_mfc	ibm_mfc	no
isa6	cga_cportiii	cga_cportiii	no
isa6	xtide	xtide	no
isa6	cga_m24	cga_m24	no
isa6	mda	isa_ibm_mda	no
isa6	num9rev	number_9_rev	no
isa6	fdc_ps2	isa8_fdc_ps2	no
isa6	ne1000	ne1000	no
isa6	ega	ega	no
isa6	pgc	isa_ibm_pgc	no
isa6	cga_poisk2	cga_poisk2	no
isa6	stereo_fx	stereo_fx	no
isa6	cga_mc1502	cga_mc1502	no
isa6	cga_ec1841	ec1841_0002	no
isa6	fdc	isa8_fdc_superio	no
isa6	cga	cga	no
isa6	sblaster1_5	isa_sblaster1_5	no
isa6	wdxt_gen	wdxt_gen	no
isa6	opus108pm	opus108pm	no
isa6	side116	side116	no
isa6	fdc_xt	isa8_fdc_xt	no
isa6	fdc_smc	isa8_fdc_smc	no
isa6	mpu401	isa_mpu401	no
isa6	sblaster1_0	isa_sblaster1_0	no
isa6	aga_pc200	isa_aga_pc200	no
isa6	hdc	isa_hdc	no
isa6	fdc344	fdc344	no
isa6	fdcmag	fdcmag	no
isa6	adlib	isa_adlib	no
isa6	ssi2001	ssi2001	no
isa6	vga	ibm_vga	no
isa6	hercules	isa_hercules	no
isa6	3xtwin	3xtwin	no
isa6	acb2072	acb2072	no
isa6	gblaster	isa_gblaster	no
isa7	babyblue2	isa_bblue2	no
isa7	epc_twib	eistwib	no
isa7	finalchs	isa_finalchs	no
isa7	epc_mda	isa_epc_mda	no
isa7	chessmsr	isa_chessmsr	no
isa7	asc88	asc88	no
isa7	pds	isa_pds	no
isa7	prose4k1	isa_prose4001	no
isa7	dectalk	dectalk_isa	no
isa7	lba_enhancer	lba_enhancer	no
isa7	wd1002a_wx1	wd1002a_wx1	no
isa7	lpt	isa_lpt	no
isa7	3c503	el2_3c503	no
isa7	pcmidi	isa_pcmidi	no
isa7	wd90c90_jk	wd90c90_jk	no
isa7	fdc_at	isa8_fdc_at	no
isa7	aga	isa_aga	no
isa7	com	isa_com	no
isa7	chessmdr	isa_chessmdr	no
isa7	ibm_mfc	ibm_mfc	no
isa7	cga_cportiii	cga_cportiii	no
isa7	xtide	xtide	no
isa7	cga_m24	cga_m24	no
isa7	mda	isa_ibm_mda	no
isa7	num9rev	number_9_rev	no
isa7	fdc_ps2	isa8_fdc_ps2	no
isa7	ne1000	ne1000	no
isa7	ega	ega	no
isa7	pgc	isa_ibm_pgc	no
isa7	cga_poisk2	cga_poisk2	no
isa7	stereo_fx	stereo_fx	no
isa7	cga_mc1502	cga_mc1502	no
isa7	cga_ec1841	ec1841_0002	no
isa7	fdc	isa8_fdc_superio	no
isa7	cga	cga	no
isa7	sblaster1_5	isa_sblaster1_5	no
isa7	wdxt_gen	wdxt_gen	no
isa7	opus108pm	opus108pm	no
isa7	side116	side116	no
isa7	fdc_xt	isa8_fdc_xt	no
isa7	fdc_smc	isa8_fdc_smc	no
isa7	mpu401	isa_mpu401	no
isa7	sblaster1_0	isa_sblaster1_0	no
isa7	aga_pc200	isa_aga_pc200	no
isa7	hdc	isa_hdc	no
isa7	fdc344	fdc344	no
isa7	fdcmag	fdcmag	no
isa7	adlib	isa_adlib	no
isa7	ssi2001	ssi2001	no
isa7	vga	ibm_vga	no
isa7	hercules	isa_hercules	no
isa7	3xtwin	3xtwin	no
isa7	acb2072	acb2072	no
isa7	gblaster	isa_gblaster	no
isa8	babyblue2	isa_bblue2	no
isa8	epc_twib	eistwib	no
isa8	finalchs	isa_finalchs	no
isa8	epc_mda	isa_epc_mda	no
isa8	chessmsr	isa_chessmsr	no
isa8	asc88	asc88	no
isa8	pds	isa_pds	no
isa8	prose4k1	isa_prose4001	no
isa8	dectalk	dectalk_isa	no
isa8	lba_enhancer	lba_enhancer	no
isa8	wd1002a_wx1	wd1002a_wx1	no
isa8	lpt	isa_lpt	no
isa8	3c503	el2_3c503	no
isa8	pcmidi	isa_pcmidi	no
isa8	wd90c90_jk	wd90c90_jk	no
isa8	fdc_at	isa8_fdc_at	no
isa8	aga	isa_aga	no
isa8	com	isa_com	no
isa8	chessmdr	isa_chessmdr	no
isa8	ibm_mfc	ibm_mfc	no
isa8	cga_cportiii	cga_cportiii	no
isa8	xtide	xtide	no
isa8	cga_m24	cga_m24	no
isa8	mda	isa_ibm_mda	no
isa8	num9rev	number_9_rev	no
isa8	fdc_ps2	isa8_fdc_ps2	no
isa8	ne1000	ne1000	no
isa8	ega	ega	no
isa8	pgc	isa_ibm_pgc	no
isa8	cga_poisk2	cga_poisk2	no
isa8	stereo_fx	stereo_fx	no
isa8	cga_mc1502	cga_mc1502	no
isa8	cga_ec1841	ec1841_0002	no
isa8	fdc	isa8_fdc_superio	no
isa8	cga	cga	no
isa8	sblaster1_5	isa_sblaster1_5	no
isa8	wdxt_gen	wdxt_gen	no
isa8	opus108pm	opus108pm	no
isa8	side116	side116	no
isa8	fdc_xt	isa8_fdc_xt	no
isa8	fdc_smc	isa8_fdc_smc	no
isa8	mpu401	isa_mpu401	no
isa8	sblaster1_0	isa_sblaster1_0	no
isa8	aga_pc200	isa_aga_pc200	no
isa8	hdc	isa_hdc	no
isa8	fdc344	fdc344	no
isa8	fdcmag	fdcmag	no
isa8	adlib	isa_adlib	no
isa8	ssi2001	ssi2001	no
isa8	vga	ibm_vga	no
isa8	hercules	isa_hercules	no
isa8	3xtwin	3xtwin	no
isa8	acb2072	acb2072	no
isa8	gblaster	isa_gblaster	no
kbd	iskr1030	kb_iskr1030	no
kbd	ec1841	kb_ec1841	no
kbd	pcxt	kb_pcxt83	yes
kbd	pc	kb_pc83	no
kbd	keytronc_pc3270	keytronic_pc3270	no

configuration

CGA character set

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA character set	isa1:cga:cga_config	3

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Alternative	1	no

CGA monitor type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA monitor type	isa1:cga:cga_config	28

setting

name	value	default
Colour RGB	0	yes
Mono RGB	4	no
Colour composite	8	no
Television	12	no
LCD	16	no

CGA chipset

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA chipset	isa1:cga:cga_config	224

setting

name	value	default
IBM	0	yes
Amstrad PC1512	32	no
Amstrad PPC512	64	no
ATI	96	no
Paradise	128	no

dipswitch

Type of 2nd drive

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type of 2nd drive	isa4:hdc:HDD	3

value

name	value	default
0	3	yes
1	2	no
2	1	no
3	0	no

Type of 1st drive

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type of 1st drive	isa4:hdc:HDD	12

value

name	value	default
0	12	yes
1	8	no
2	4	no
3	0	no

IRQ level

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
IRQ level	isa4:hdc:HDD	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5	64	yes
2	0	no

Install ROM?

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Install ROM?	isa4:hdc:ROM	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Yes	1	yes
No	0	no

Boot from floppy

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Boot from floppy	mb:DSW0	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Yes	1	yes
No	0	no

8087 installed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
8087 installed	mb:DSW0	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	2	no

RAM banks

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RAM banks	mb:DSW0	12

location

name	number	inverted
SW1	3	no
SW1	4	no

value

name	value	default
1 - 16/ 64/256K	0	no
2 - 32/128/512K	4	no
3 - 48/192/576K	8	no
4 - 64/256/640K	12	yes

Graphics adapter

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Graphics adapter	mb:DSW0	48

location

name	number	inverted
SW1	5	no
SW1	6	no

value

name	value	default
EGA/VGA	0	no
Color 40x25	16	no
Color 80x25	32	yes
Monochrome	48	no

Number of floppy drives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Number of floppy drives	mb:DSW0	192

location

name	number	inverted
SW1	7	no
SW1	8	no

value

name	value	default
1	0	no
2	64	yes
3	128	no
4	192	no
