PVI-486SP3 (SiS 85C496/85C497) - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
a486sp3	pc/pcipc_sis.cpp		no	no	no	yes	PVI-486SP3 (SiS 85C496/85C497)	1994	Asus

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
isa1:wd90c31_lr:screen	raster	0	640	480	60.054866	25175000	800	0	640	524	0	480	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	status	optional	bios
awsi0207.bin	131072	0cb862aa	7ffead05c1df47ec36afba395191145279c5e789	pci:05.0	good	no	v207
awsi2737.bin	131072	8cd9a89c	6c68c23cc5e8ae66261e9fe931f2ce07efe767b6	pci:05.0	good	no	v2737
si4i0306.awd	131072	fc70371a	96b10cfa97c5d1d023687f01e8acb54f263069b2	pci:05.0	good	no	v306
si4i0307h.bin	131072	99473cc0	a01d253cf434a31e0ca6f6cd2b9026ca424eb463	pci:05.0	good	no	v307
4siw003.bin	131072	47a1d815	370bfb895646518884a2a82881721efc3aeb04d1	pci:05.0	good	no	v301
0101.bin	131072	7862ca56	e609585893b23db10c4ae7d2abd17cc9dda964b6	pci:05.0	good	no	v10101
si4i0101.awd	131072	18652037	7460e90b0a9c825d2e47943a714049fe9e943760	pci:05.0	good	no	v10102
si4i0205.awd	131072	d90d91b0	043151d121780ff56ce32b9a48e9bbccd324625f	pci:05.0	good	no	v205
si4i0305.awd	131072	2f90e63e	a4f16753b5a57d65fba7702ca28e44f10bd5bb6c	pci:05.0	good	no	v305

chip

type	tag	name	clock
cpu	maincpu	Intel I486DX4	75000000
cpu	pci:05.0:dma8237_1	AM9517A	4772727
cpu	pci:05.0:dma8237_2	AM9517A	4772727
cpu	pci:05.0:keybc:mcu	Intel 8042AH	12000000
cpu	pci:05.0:kbd:ms_naturl:ms_natrl_cpu	Intel 8051	6000000
audio	pci:05.0:ide2:0:cdrom:cdda	CD/DA	44100
audio	pci:05.0:mono	Speaker
audio	pci:05.0:speaker	Filtered DAC

device_ref

name
i486dx4
pci_root
sis85c496_host
am9517a
am9517a
pic8259
pic8259
pit8254
pit_counter
pit_counter
pit_counter
at_keybc
i8042ah
pc_kbdc
kb_ms_natural
i8051
ds12885
isa16
idectrl32
ata_slot
idehd
harddisk_image
ata_slot
idectrl32
ata_slot
cdrom
cdrom_image
cdda
ata_slot
speaker
speaker_sound_device
isa16_slot
w83787f
pc_lpt
centronics
centronics_printer
printer_image
input_buffer
input_buffer
input_buffer
output_latch
output_latch
ns16550
ns16550
isa16_slot
wd90c31_lr
screen
wd90c31_vga
isa16_slot
isa16_slot
rs232
rs232_mouse_hle_logitech
rs232

biosset

name	description	default
v207	ASUS PVI-486SP3 V2.07	no
v2737	ASUS PVI-486SP3 V2.07 #2	no
v306	ASUS PVI-486SP3 V3.06	no
v307	ASUS PVI-486SP3 V3.07	no
v301	ASUS PVI-486SP3 V3.01	no
v10101	ASUS PVI-486SP3 V1.01 #1	no
v10102	ASUS PVI-486SP3 V1.01 #2	no
v205	ASUS PVI-486SP3 V2.05	no
v305	ASUS PCI/I-486SP3 V3.05	no

sound

channels
1

feature

type	status	overall
graphics		imperfect

device, instance

type	tag	interface	name	briefname
harddisk	pci:05.0:ide1:0:hdd:image	ide_hdd,hdd	harddisk	hard
cdrom	pci:05.0:ide2:0:cdrom:image	cdrom	cdrom	cdrm
printout	board4:w83787f:lpta:centronics:printer:printer		printout	prin

device, extension

type	tag	interface	extension_names
harddisk	pci:05.0:ide1:0:hdd:image	ide_hdd,hdd	chd, hd, hdv, 2mg, hdi
cdrom	pci:05.0:ide2:0:cdrom:image	cdrom	chd, cue, toc, nrg, gdi, iso, cdr
printout	board4:w83787f:lpta:centronics:printer:printer		prn

input

players	coins	service	tilt
1		no	no

control
