Portable III - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
comportiii	pc/at.cpp		no	no	no	yes	Portable III	1987	Compaq	ibm5170	ibm5170

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
board4:cga_cportiii:screen	raster	0	640	400	33.982164	14318181	912	0	640	462	0	400	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	bios
cpiii_87c128_106779-002.bin	16384	aef8f532	b0374d5aa8766f11043cbaee007e6d311f792e44	bios	18000	good	no	106779-002
cpiii_87c128_106778-002.bin	16384	c259f628	df0ca8aaead617114fbecb4ececbd1a3bb1d5f30	bios	18001	good	no	106779-002
109738-002.bin	32768	db131b8a	6a8517a771272edf16870501fc1ed94c7555ef45	bios	10000	good	no	109737-002
109737-002.bin	32768	8463cc41	cb9801591e4a2cd13bbcc40739c9e675ba84c079	bios	10001	good	no	109737-002

chip

type	tag	name	clock
cpu	maincpu	Intel 80286	12000000
cpu	mb:dma8237_1	AM9517A	4772727
cpu	mb:dma8237_2	AM9517A	4772727
cpu	mb:keybc:mcu	Intel 8042AH	12000000
cpu	kbd:pcat:m5	Intel 8048	5364000
audio	mb:mono	Speaker
audio	mb:speaker	Filtered DAC
audio	board1:fdc:fdc:0:525hd:flopsndout	Speaker
audio	board1:fdc:fdc:0:525hd:floppysound	Floppy sound	44100

softwarelist

tag	name	status
pc_disk_list	ibm5150	original
at_disk_list	ibm5170	original
at_cdrom_list	ibm5170_cdrom	original
at_hdd_list	ibm5170_hdd	original
midi_disk_list	midi_flop	compatible

device_ref

name
i80286
at_mb
pit8254
pit_counter
pit_counter
pit_counter
am9517a
am9517a
pic8259
pic8259
isa16
mc146818
speaker
speaker_sound_device
at_keybc
i8042ah
software_list
software_list
software_list
software_list
software_list
isa16_slot
isa8_fdc_at
upd765a
floppy_connector
floppy_525_hd
speaker
flopsnd
floppy_connector
isa16_slot
isa_com_at
ns16450
ns16450
rs232
rs232_mouse_hle_logitech
rs232
isa16_slot
isa_hdc
xt_hdc
harddisk_image
harddisk_image
isa16_slot
cga_cportiii
screen
palette
hd6845s
isa16_slot
isa16_slot
pc_kbdc
kb_pcat84
i8048
ram

biosset

name	description	default
106779-002	106779-002	no
109737-002	109737-002	no

sound

channels
2

feature

type	status	overall
graphics		imperfect

ramoption

name	default
1152K
1664K
2176K
2688K
4736K
6784K
640K	yes

device, instance

type	tag	interface	name	briefname
floppydisk	board1:fdc:fdc:0:525hd	floppy_5_25	floppydisk	flop
harddisk	board3:hdc:hdc:primary	st_hdd	harddisk1	hard1
harddisk	board3:hdc:hdc:slave	st_hdd	harddisk2	hard2

device, extension

type	tag	interface	extension_names
floppydisk	board1:fdc:fdc:0:525hd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf, xdf
harddisk	board3:hdc:hdc:primary	st_hdd	chd, hd, hdv, 2mg, hdi
harddisk	board3:hdc:hdc:slave	st_hdd	chd, hd, hdv, 2mg, hdi

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
mouse		3		no	0	61440	100
keyboard		84		no

port, analog

port_tag	analog_masks
:board2:comat:serport0:logitech_mouse:BTN
:board2:comat:serport0:logitech_mouse:X	4095
:board2:comat:serport0:logitech_mouse:Y	4095
:board3:hdc:HDD
:board3:hdc:ROM
:board4:cga_cportiii:cga_config
:kbd:pcat:DR00
:kbd:pcat:DR01
:kbd:pcat:DR02
:kbd:pcat:DR03
:kbd:pcat:DR04
:kbd:pcat:DR05
:kbd:pcat:DR06
:kbd:pcat:DR07
:kbd:pcat:DR08
:kbd:pcat:DR09
:kbd:pcat:DR10
:kbd:pcat:DR11
:kbd:pcat:DR12
:kbd:pcat:DR13
:kbd:pcat:DR14
:kbd:pcat:DR15
:mb:keybc:P1

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
board1:fdc:fdc:0	35dd	floppy_35_dd	no
board1:fdc:fdc:0	525dd	floppy_525_dd	no
board1:fdc:fdc:0	35hd	floppy_35_hd	no
board1:fdc:fdc:0	525hd	floppy_525_hd	yes
board1:fdc:fdc:1	35dd	floppy_35_dd	no
board1:fdc:fdc:1	525dd	floppy_525_dd	no
board1:fdc:fdc:1	35hd	floppy_35_hd	no
board1:fdc:fdc:1	525hd	floppy_525_hd	no
board2:comat:serport0	null_modem	null_modem	no
board2:comat:serport0	terminal	serial_terminal	no
board2:comat:serport0	msystems_mouse	rs232_mouse_hle_msystems	no
board2:comat:serport0	sun_kbd	sunkbd_adaptor	no
board2:comat:serport0	wheel_mouse	rs232_mouse_hle_wheel	no
board2:comat:serport0	rotatable_mouse	rs232_mouse_hle_rotatable	no
board2:comat:serport0	logitech_mouse	rs232_mouse_hle_logitech	yes
board2:comat:serport0	microsoft_mouse	rs232_mouse_hle_msft	no
board2:comat:serport1	null_modem	null_modem	no
board2:comat:serport1	terminal	serial_terminal	no
board2:comat:serport1	msystems_mouse	rs232_mouse_hle_msystems	no
board2:comat:serport1	sun_kbd	sunkbd_adaptor	no
board2:comat:serport1	wheel_mouse	rs232_mouse_hle_wheel	no
board2:comat:serport1	rotatable_mouse	rs232_mouse_hle_rotatable	no
board2:comat:serport1	logitech_mouse	rs232_mouse_hle_logitech	no
board2:comat:serport1	microsoft_mouse	rs232_mouse_hle_msft	no
isa1	hpblp	hpblp	no
isa1	lrk331	lrk331	no
isa1	omti8621	omti8621isa	no
isa1	dc820b	dc820b	no
isa1	dc320e	dc320e	no
isa1	dc320b	dc320b	no
isa1	ultra12f32	ultra12f32	no
isa1	ex1280	ex1280	no
isa1	bt542b	bt542b	no
isa1	ev346	ev346	no
isa1	wd1007a	wd1007a	no
isa1	np600a3	np600a3	no
isa1	bt542bh	bt542bh	no
isa1	3c505	3c505	no
isa1	wd90c33_zz	wd90c33_zz	no
isa1	wd90c31a_lr	wd90c31a_lr	no
isa1	wd90c30_lr	wd90c30_lr	no
isa1	dc820	dc820	no
isa1	ultra14f	ultra14f	no
isa1	ultra12f	ultra12f	no
isa1	wd90c11_lr	wd90c11_lr	no
isa1	svga_et4kw32i	et4kw32i	no
isa1	sb16_lle	sb16	no
isa1	svga_et4k	et4000	no
isa1	mcd	mcd_isa	no
isa1	pvga1a_jk	pvga1a_jk	no
isa1	pvga1a	pvga1a	no
isa1	pgc	isa_ibm_pgc	no
isa1	pcmidi	isa_pcmidi	no
isa1	3c503	el2_3c503	no
isa1	svga_s3	s3_764	no
isa1	vga	ibm_vga	no
isa1	ibm_mfc	ibm_mfc	no
isa1	cga_cportiii	cga_cportiii	no
isa1	chessmdr	isa_chessmdr	no
isa1	gblaster	isa_gblaster	no
isa1	wd90c00_jk	wd90c00_jk	no
isa1	acb2072	acb2072	no
isa1	3xtwin	3xtwin	no
isa1	sblaster1_0	isa_sblaster1_0	no
isa1	mpu401	isa_mpu401	no
isa1	sad8852	sad8852	no
isa1	fdc344	fdc344	no
isa1	adlib	isa_adlib	no
isa1	side116	side116	no
isa1	cga	cga	no
isa1	comat	isa_com_at	no
isa1	num9rev	number_9_rev	no
isa1	wd90c90_jk	wd90c90_jk	no
isa1	fdc	isa8_fdc_at	no
isa1	stereo_fx	stereo_fx	no
isa1	bt545s	bt545s	no
isa1	mda	isa_ibm_mda	no
isa1	lpt	isa_lpt	no
isa1	ega	ega	no
isa1	aha1542b	aha1542b	no
isa1	wd90c31a_zs	wd90c31a_zs	no
isa1	fdcmag	fdcmag	no
isa1	sblaster1_5	isa_sblaster1_5	no
isa1	wd90c31_lr	wd90c31_lr	no
isa1	hercules	isa_hercules	no
isa1	fdcsmc	isa8_fdc_smc	no
isa1	jc1310	jc1310	no
isa1	dectalk	dectalk_isa	no
isa1	aha1542cp	aha1542cp	no
isa1	prose4k1	isa_prose4001	no
isa1	pds	isa_pds	no
isa1	wyse700	wyse700	no
isa1	lba_enhancer	lba_enhancer	no
isa1	chessmsr	isa_chessmsr	no
isa1	epc_mda	isa_epc_mda	no
isa1	ultra24f	ultra24f	no
isa1	finalchs	isa_finalchs	no
isa1	epc_twib	eistwib	no
isa1	com	isa_com	no
isa1	babyblue2	isa_bblue2	no
isa1	gus	isa_gus	no
isa1	svga_et4k_kasan16	et4000_kasan16	no
isa1	ne1000	ne1000	no
isa1	opus108pm	opus108pm	no
isa1	ibm_speech	isa_ibm_speech	no
isa1	ide	isa_ide	no
isa1	ssi2001	ssi2001	no
isa1	ne2000	ne2000	no
isa1	mach64	mach64isa	no
isa1	aha1742a	aha1742a	no
isa1	tvga9000	tvga9000	no
isa1	hdc	isa_hdc	no
isa1	aha1542a	aha1542a	no
isa1	aha1542c	aha1542c	no
isa1	aha1542cf	aha1542cf	no
isa1	dcb	novell_dcb	no
isa1	sblaster_16	isa_sblaster_16	no
isa1	svga_dm	dm_clgd5430	no
isa1	gfxultrap	gfxultrap	no
isa1	aha1740	aha1740	no
isa1	clgd542x	clgd542x	no
isa1	gfxultra	gfxultra	no
isa2	hpblp	hpblp	no
isa2	lrk331	lrk331	no
isa2	omti8621	omti8621isa	no
isa2	dc820b	dc820b	no
isa2	dc320e	dc320e	no
isa2	dc320b	dc320b	no
isa2	ultra12f32	ultra12f32	no
isa2	ex1280	ex1280	no
isa2	bt542b	bt542b	no
isa2	ev346	ev346	no
isa2	wd1007a	wd1007a	no
isa2	np600a3	np600a3	no
isa2	bt542bh	bt542bh	no
isa2	3c505	3c505	no
isa2	wd90c33_zz	wd90c33_zz	no
isa2	wd90c31a_lr	wd90c31a_lr	no
isa2	wd90c30_lr	wd90c30_lr	no
isa2	dc820	dc820	no
isa2	ultra14f	ultra14f	no
isa2	ultra12f	ultra12f	no
isa2	wd90c11_lr	wd90c11_lr	no
isa2	svga_et4kw32i	et4kw32i	no
isa2	sb16_lle	sb16	no
isa2	svga_et4k	et4000	no
isa2	mcd	mcd_isa	no
isa2	pvga1a_jk	pvga1a_jk	no
isa2	pvga1a	pvga1a	no
isa2	pgc	isa_ibm_pgc	no
isa2	pcmidi	isa_pcmidi	no
isa2	3c503	el2_3c503	no
isa2	svga_s3	s3_764	no
isa2	vga	ibm_vga	no
isa2	ibm_mfc	ibm_mfc	no
isa2	cga_cportiii	cga_cportiii	no
isa2	chessmdr	isa_chessmdr	no
isa2	gblaster	isa_gblaster	no
isa2	wd90c00_jk	wd90c00_jk	no
isa2	acb2072	acb2072	no
isa2	3xtwin	3xtwin	no
isa2	sblaster1_0	isa_sblaster1_0	no
isa2	mpu401	isa_mpu401	no
isa2	sad8852	sad8852	no
isa2	fdc344	fdc344	no
isa2	adlib	isa_adlib	no
isa2	side116	side116	no
isa2	cga	cga	no
isa2	comat	isa_com_at	no
isa2	num9rev	number_9_rev	no
isa2	wd90c90_jk	wd90c90_jk	no
isa2	fdc	isa8_fdc_at	no
isa2	stereo_fx	stereo_fx	no
isa2	bt545s	bt545s	no
isa2	mda	isa_ibm_mda	no
isa2	lpt	isa_lpt	no
isa2	ega	ega	no
isa2	aha1542b	aha1542b	no
isa2	wd90c31a_zs	wd90c31a_zs	no
isa2	fdcmag	fdcmag	no
isa2	sblaster1_5	isa_sblaster1_5	no
isa2	wd90c31_lr	wd90c31_lr	no
isa2	hercules	isa_hercules	no
isa2	fdcsmc	isa8_fdc_smc	no
isa2	jc1310	jc1310	no
isa2	dectalk	dectalk_isa	no
isa2	aha1542cp	aha1542cp	no
isa2	prose4k1	isa_prose4001	no
isa2	pds	isa_pds	no
isa2	wyse700	wyse700	no
isa2	lba_enhancer	lba_enhancer	no
isa2	chessmsr	isa_chessmsr	no
isa2	epc_mda	isa_epc_mda	no
isa2	ultra24f	ultra24f	no
isa2	finalchs	isa_finalchs	no
isa2	epc_twib	eistwib	no
isa2	com	isa_com	no
isa2	babyblue2	isa_bblue2	no
isa2	gus	isa_gus	no
isa2	svga_et4k_kasan16	et4000_kasan16	no
isa2	ne1000	ne1000	no
isa2	opus108pm	opus108pm	no
isa2	ibm_speech	isa_ibm_speech	no
isa2	ide	isa_ide	no
isa2	ssi2001	ssi2001	no
isa2	ne2000	ne2000	no
isa2	mach64	mach64isa	no
isa2	aha1742a	aha1742a	no
isa2	tvga9000	tvga9000	no
isa2	hdc	isa_hdc	no
isa2	aha1542a	aha1542a	no
isa2	aha1542c	aha1542c	no
isa2	aha1542cf	aha1542cf	no
isa2	dcb	novell_dcb	no
isa2	sblaster_16	isa_sblaster_16	no
isa2	svga_dm	dm_clgd5430	no
isa2	gfxultrap	gfxultrap	no
isa2	aha1740	aha1740	no
isa2	clgd542x	clgd542x	no
isa2	gfxultra	gfxultra	no
kbd	g80_1500	g80_1500	no
kbd	pcat101	kb_pcat101	no
kbd	pcat	kb_pcat84	yes
kbd	ms_naturl	kb_ms_natural	no
kbd	3270pc	kb_3270pc	no
kbd	keytronc_pc3270	keytronic_pc3270_at	no

configuration

CGA character set

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA character set	board4:cga_cportiii:cga_config	3

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	0	yes
Alternative	1	no

CGA monitor type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA monitor type	board4:cga_cportiii:cga_config	28

setting

name	value	default
Colour RGB	0	yes
Mono RGB	4	no
Colour composite	8	no
Television	12	no
LCD	16	no

CGA chipset

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CGA chipset	board4:cga_cportiii:cga_config	224

setting

name	value	default
IBM	0	yes
Amstrad PC1512	32	no
Amstrad PPC512	64	no
ATI	96	no
Paradise	128	no

CRT Adapter Switch

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CRT Adapter Switch	mb:keybc:P1	64

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Monochrome Display Adapter	64	no
Color Graphics Adapter	0	yes

Key Lock

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Key Lock	mb:keybc:P1	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

dipswitch

Type of 2nd drive

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type of 2nd drive	board3:hdc:HDD	3

value

name	value	default
0	3	yes
1	2	no
2	1	no
3	0	no

Type of 1st drive

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type of 1st drive	board3:hdc:HDD	12

value

name	value	default
0	12	yes
1	8	no
2	4	no
3	0	no

IRQ level

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
IRQ level	board3:hdc:HDD	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5	64	yes
2	0	no

Install ROM?

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Install ROM?	board3:hdc:ROM	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Yes	1	yes
No	0	no
